1. Define the data model

In this chapter you create the three models that the rest of the tutorial builds on.

Estimated time: 20 minutes.

1.1 Create the Lead model

Open Studio → Models → New model. Fill in:

• Code: crm_lead
• Display name: Lead
• Tenant: your tenant
• Storage: standard (auto-creates the mt_crm_lead table)

Add the following fields:

Save and publish. The platform will create the dynamic table automatically (see Models & Fields).

1.2 Create the Account model

# DSL snippet — for reference, you can edit this in Studio.
model:
  code: crm_account
  fields:
    - { code: name,    type: string(120), required: true, unique: true }
    - { code: domain,  type: string(80) }
    - { code: tier,    type: enum, values: [strategic, growth, smb] }
    - { code: owner,   type: ref, target: sys_user }

1.3 Create the Opportunity model

Opportunity references Account and has stage + amount.

model:
  code: crm_opportunity
  fields:
    - { code: title,    type: string(160), required: true }
    - { code: account,  type: ref, target: crm_account, required: true, onDelete: restrict }
    - { code: stage,    type: enum, values: [prospect, qualified, proposal, won, lost], default: prospect }
    - { code: amount,   type: decimal(14,2) }
    - { code: close_at, type: date }
    - { code: owner,    type: ref, target: sys_user }

1.4 Validation rules

Add these constraints in Studio → Models → Validation:

• Lead.email — unique within tenant
• Opportunity.amount — non-negative
• Opportunity.close_at — must be in the future when stage != won|lost

1.5 Verify

Open Data → Tables and confirm:

• mt_crm_lead, mt_crm_account, mt_crm_opportunity exist
• Each row has id (snowflake) and pid (ULID) populated automatically
• The reference column crm_opportunity.account_id has a foreign key to mt_crm_account.id

If any of these are missing, re-publish the model and re-check; the platform calls SchemaManagementServiceImpl.createTableByModel on publish.

Next

Chapter 2 → Design the pages
